Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. During the first 1,600 km (1,000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in. INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control. If it comes on ENGINE after the engine is started, one of SOON the engine’s emission control systems may be malfunctioning. The light may illuminate without a driveability concern being noted. Check the fuel FUEL cap for proper installation. When the fuel filler cap is properly re-installed, the light(s) will turn off after a period of normal driving.Refer to Engine coolant temperature gauge, Engine oil pressure gauge or Fuel gauge in this chapter for more information. If the lights stay on continuously or flash faster, check for a burned-out bulb. High beams Illuminates when the high beam headlamps are turned on. Low washer fluid (if equipped) Illuminates when the windshield washer fluid is low. If the light does not come on or the light flashes steadily, have your vehicle serviced as soon as possible, damage to the transmission could occur. Speed control Illuminates when the speed control is activated. At normal operating temperature, the needle remains within the normal area (the indicated area between the “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool.http://www.szpital-sulecin.pl/images/fckfiles/02-nissan-pathfinder-owners-manual.xml
At normal operating temperature, the needle will be in the normal range (the area between the “L” and “H”); if the needle goes below the normal range, stop the vehicle as soon as safely possible and switch off the engine immediately. If the compass still appears to be inaccurate, a manual calibration may be necessary. Refer to Compass calibration adjustment. A correct zone setting will eliminate this error.This will take up to three circles to complete calibration. 10. The compass is now calibrated. Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel. To operate the Trip Elapsed Drive Time perform the following: 1. Press and release RESET in order to start the timer. 2. Press and release RESET to pause the timer. 3. System check Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored. Indicates the transmission is overheating. This warning may appear when towing heavy loads or when driving in a low gear at a high speed for an extended period of time. Stop the vehicle as soon as safely possible, turn off the engine and let it cool. Displayed when the Tire pressure monitoring system is malfunctioning. If the warning stays on or continues to come on, have the system checked by your dealer. TIRE PRESSURE SENSOR FAULT (if equipped). Displayed when a Tire pressure sensor is malfunctioning. Displayed when the tire pressure monitoring system is turned off. Only your dealer can turn the system on or off. It is recommended that the tire pressure monitoring system is always turned ON. DATA ERR. Rotate clockwise to the second position to also turn on the headlamps. Foglamp control (if equipped) The headlamp control also operates the foglamps. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp parklamp operation.http://www.nursing.com.pl/images/02-nissan-sentra-service-manual.xml
The autolamp system also keeps the lights on for approximately 20 seconds or a programmed time delay after the ignition switch is turned to the OFF position. As you move closer to the obstacle, the rate of the tone increases. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle. It can be used to clear ice or fog from the windshield.This will reduce fogging on your windshield.Do not place objects on top of the instrument panel, as these objects may become projectiles in a collision or sudden stop. The DEATC system will only operate when the ignition is in the ON position. Turning the DEATC system off Press OFF. Additionally, if the engine is not warm enough to provide heat, the fan will operate at a low speed and the airflow will be directed to the windshield or to the floor. The fan speed will start to increase and the airflow location will change to the floor area. You can override fan speed at any time. To control fan speed manually, press the fan control to cancel the automatic fan speed operation. The air conditioning compressor can operate in all modes except OFF. For added customer comfort, the air distributed through the floor ducts may be slightly warmer than the air sent to the windshield defroster ducts. Following this, the outside temperature display will return to the window. The outside temperature reading is most accurate when the vehicle is moving. To control the auxiliary climate control system from the front controls, turn the fan speed control knob to the desired speed. Ensure that the front auxiliary control is turned to REAR to enable the rear climate controls. Turn the fan speed control to the desired fan speed. The icon will illuminate on the temperature selector. Only the auxiliary control head (front or rear) that is active will have the indicator lights functioning.http://www.drupalitalia.org/node/65934
Floor console climate controls (if equipped) Depending on the equipment package, your vehicle may be equipped with floor console climate control capabilities. To select air flow from the panel registers of the console, slide the control to. To select airflow from the registers of the floor console, slide the control to To stop the air from flowing through the floor console: 1. Press the control to switch between AM, FM1 or FM2 memory preset stations.If a selection has been playing for three seconds or more and you press, the CD will replay that selection from the beginning. SIDE 1-2 COMP SHUFFLE Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. Treble adjust The treble adjust control allows you BASS TREB to increase or decrease the audio system’s treble output.Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD SHUFFLE mode and plays all tracks in random order. If your vehicle has a separate clock, (other than the digital radio display), the CLK control will not function in the above manner. The CLK control will allow you to switch between media display mode AUTO (radio station, stereo information,. Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”. The selected level will appear in the display.SEEK UP will display.Press the TUNE control to go up or down the listening band in individual increments. 3. Select a station. Refer to Seek function for more information on selecting a station. Load the CD into the audio system. The first track of the disc will begin playing. After that, CD play will begin where it stopped last. If you do not choose a slot, the system will choose the next available one.) Wait until the CD door opens. Load the CD into the player.ACKTIVITIES.COM/images/02-mercury-sable-owners-manual.pdf
Press and hold the REW control until the desired selection is reached. If the beginning of the disc is reached, the CD will begin play at the first track. Release the control to disengage rewind mode. TREB Press the TREB control. Use the SEL control to increase or decrease the amount of treble. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. With the RDS activated, press the MENU control until TRAFFIC ON is displayed. Press the MENU control until FIND program type is displayed. MENU Use the SEL control to select the program type.Press the MENU control again to disengage the clock mode. Troubleshooting the CD changer (if equipped) The laser beam used in the compact disc player is harmful to the eyes. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles).Once speed control is switched off, the previously programmed set speed will be erased.Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.While the lever is in the down position, tilt and telescope the steering column to the desired orientation. The bars of varying length are for intermittent wipers. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Storage compartment Press the latch to open the storage compartment. Once fully closed, the rear of the glass panel will appear higher than the front edge.
To vent: To tilt the moon roof into the vent position (when the glass panel is closed), press and hold the front portion of the control. The cargo lamp will stay on if the control is moved to the passenger side position. It is also suggested that upon the sale of the vehicle, the programmed Homelink Universal Transceiver buttons be erased for security purposes, refer to Programming in this section. If the light is a constant red, programming is complete and your device should activate when the HomeLink button is pressed and released. Note: To program the remaining two HomeLink buttons, begin with step 2 in the “Programming”. After completing steps 1 and 2 outlined in the “Programming” section, replace step 3 with the following: Note: If programming a garage door opener or gate operator, it is. Release both buttons. Do not hold for longer that 30 seconds. The driver’s window will open fully. One touch down can be deactivated during operation by pushing down on the top part of the driver power AUTO window control. Press control to lock all doors.The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. The power point is an additional power source for electrical accessories. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. This will also prevent passengers and cargo from falling out. CARGO COVER (IF EQUIPPED) Your vehicle may be equipped with a cargo area cover that covers the luggage compartment of your vehicle. The interior lamps will illuminate with the ignition OFF.
Press the control a second time within three seconds to unlock all doors and liftgate.Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. Enter each digit within five seconds of the previous one. If more than five seconds pass between pressing numbers, enter the code again. The system has shut down if the keypad light is out. This can be done only when the driver’s door is closed.If the procedure needs to be repeated, you must wait 30 seconds. 1. Turn the ignition key to ON. 2. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL remote entry transmitters are brought to the dealership, to aid in troubleshooting. PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help prevent your vehicle from unauthorized entry. The system is ready to arm whenever the key is removed from the ignition. Turn the key full travel (toward the front of the vehicle) to make sure the alarm disarms. This will only shut off the horn and parking lamps when the alarm is sounding.Check to make sure the coded key is an approved Mercury coded key.The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. The memory seat control is located on the driver door.
Turn the lumbar support control toward the rear of vehicle to move the lumbar support back for less direct support. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible. To enter the 3rd row seat: 1. Fold down the 2nd row seat. 2. Always latch the vehicle seat to the floor, whether the seat is occupied or empty. To access the storage space pull up on the strap.To put seat in upright position: 1. Pull back the slider panel on the seatback to release the closeout panel. 2. Pull the seat release lever located on top of the seatback while lifting the seatback into the upright position. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations. A higher energy level is used for the most severe impacts. Refer to Air bag Supplemental Restraints section in this chapter. Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Routine maintenance of the Personal Safety System is not required. The Restraints Control Module (RCM) monitors its own internal circuits and the circuits for the air bag supplemental restraints, crash sensor(s), safety belt pretensioners, front safety belt buckle sensors, and the driver seat position sensor. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. Make sure the tongue is securely fastened in the buckle. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt.In addition, all seat belts should be checked for proper function.
To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle. To fasten, grasp the tongue, and with a continuous motion, pull out enough webbing to buckle the tongue into the correct buckle. If you did not pull out enough webbing to reach the buckle, allow the tongue to retract fully before trying to pull it out. The driver and the right front passenger seat belt system (including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in deployment of front air bags and safety belt pretensioners. Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If. The purpose of the BeltMinder is to remind occasional wearers to wear safety belts all of the time. Safety belt maintenance Inspect the safety belt systems periodically to make sure they work properly and are not damaged. Inspect the safety belts to make sure there are no nicks, tears or cuts. Replace if necessary. All safety belt assemblies, including retractors, buckles, front seat belt buckle assemblies, buckle support assemblies (slide bar-if equipped), shoulder belt height adjusters (if equipped), shoulder belt guide on seatback (if. This information will assist Ford Motor Company in servicing the vehicle and in helping to better understand real world collisions and further improve the safety of future vehicles. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and non-Ford tow hooks may effect the performance of the air bag sensors increasing the risk of injury. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the. The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS and Safety Canopy system is provided. Do not touch them after inflation. If the Safety Canopy system has deployed, the Safety Canopy will not function again. The Safety Canopy system (including the A, B and C pillar trim) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual. Also see Air bag supplemental restraint system (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until.
The tether strap may not work properly if attached somewhere other than the correct tether anchor. 1. Position the child safety seat on the rear seat cushion. 2. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting. STARTING THE ENGINE Note: Whenever you start your vehicle, release the key as soon as the engine starts. Consult your fuel distributor for the availability of winter grade ethanol. Do not crank the engine for more than 30 seconds at a time as starter damage may occur. Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied. The wheels are prevented from locking even when the brakes are firmly applied. The accompanying illustration depicts the advantage of an ABS equipped vehicle (on bottom) to a non-ABS equipped vehicle (on top) during hard braking with loss of front braking traction. Once a panic brake application is detected, the system will remain activated as long as the brake pedal is depressed. The system is deactivated by releasing the brake pedal. When the system activates, the brake pedal will travel with very little effort;.
Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC STABILITY ENHANCEMENT SYSTEM (IF EQUIPPED) The AdvanceTrac system provides a stability enhancement feature as well as a traction enhancement feature. Some drivers may notice a slight movement of the brake pedal when the AdvanceTrac performs a system self-check. Power steering uses energy from the engine to decrease the driver’s effort in steering the vehicle.Extra precautions, such as slower speeds and increased stopping distance, should be taken when driving a heavily loaded vehicle. Your vehicle has the capability to haul more cargo and people than most passenger cars. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). The transmission, with overdrive off, operates in gears one through four, providing more engine braking than D(Drive) with Overdrive ON and is useful whenever driving conditions (i.e., city traffic, hilly terrain, etc.) cause the transmission to excessively shift between D (Overdrive) and other gears. The transmission will downshift to the appropriate gear: fourth, third, second or first gear. ALL WHEEL DRIVE (AWD) SYSTEM (IF EQUIPPED) Your vehicle is equipped with a full-time All Wheel Drive (AWD) transfer case. Map out your route before driving in the area. To maintain steering and braking control of your vehicle, you must have all four wheels on the ground and they must be rolling, not sliding or spinning.Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicle can’t. Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. If the front or rear axle is submerged in water, the axle lubricant should be replaced. After driving through mud, clean off residue stuck to rotating driveshafts and tires. Excess mud stuck on tires and rotating driveshafts causes an imbalance that could damage drive components. Do not descend in neutral, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control. If you nevertheless decide to equip your AWD for off-road use with tires larger than what Ford Motor Company recommends, you should not use these tires for highway driving. If one looks lower than the others, use a tire gauge to check pressure of all tires, and adjust if required. Check tire pressure with a tire gauge every few weeks (including spare). Under normal conditions, the limited slip axle functions like a standard rear axle. Extended use of other than the manufacturer’s specified size tires on a limited slip rear axle could result in a permanent reduction in effectiveness. Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles. Have the fluid checked and, if water is found, replace the fluid. TRAILER TOWING Trailer towing with your vehicle may require the use of a trailer tow option package. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. An example of recreational towing is towing your vehicle behind a motorhome.Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. In Canada, the card is found in the Owner Information Guide in the glove compartment.
Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3. To access the relays you must remove the passenger compartment fuse panel.The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. Instead, gradually decrease your speed. The spare tire winch drive nut is located at the rear center of the cargo area under a lid. This will damage the spare tire winch. 1. Open the cover from the carpeting on cargo floor to expose the winch drive nut. 2. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving. Do not start the engine when your vehicle is on the jack.The lug wrench will click when the tire is raised to the stowed position. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. Connecting the jumper cables 1. Connecting to any other exposed component may cause an explosion. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. If your vehicle requires professional service, your dealership can provide the necessary parts and service. Some oil must be removed from the engine by a service technician. 7.
Put the indicator back in and ensure it is fully seated. Adding engine oil 1. SAE 5W-30 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API).Refer to the scheduled maintenance guide for the service interval schedules. 1. Clean the reservoir cap before removal to prevent dirt or water from entering the reservoir. The reservoir is highlighted with a symbol. Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. If the concentration of coolant falls below 40% or above 60%, the engine parts could become damaged or not work properly.If sprayed on the windshield, engine coolant could make it difficult to see through the windshield.Add the proper mixture of coolant and water to the “cold full” level. For all other vehicles, which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Be sure to put the cap back on the reservoir. TRANSMISSION FLUID Checking automatic transmission fluid The automatic transmission does not have a transmission fluid dipstick. Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in the Capacities and specifications chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication. For longer, trouble-free operation, keep the top of the battery clean and dry.
